Name: M19 Watertight Power Connector 300V 5 Pin Panel Mount Quick Lock Connector
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M19
Availability: InStock

Aperçu Produits Connecteur circulaire étanche à l'eau

M19 Watertight Power Connector 300V 5 Pin Panel Mount Quick Lock Connector

Détails sur le produit:

Lieu d'origine:	Chine
Nom de marque:	Ulinkcon
Certification:	CE/Rohs/TUV/UL
Numéro de modèle:	M19

Conditions de paiement et expédition:

Quantité de commande min:	Négociation
Prix:	Négociable
Détails d'emballage:	1. Sac en plastique ; 2. Carton ; 3. Selon les exigences du client
Délai de livraison:	3 ~ 6 jours ouvrables
Conditions de paiement:	T/T, D/P, L/C, D/A, Western Union, MoneyGram
Capacité d'approvisionnement:	100 000 paires mensuellement

Contact

Description de produit détaillée

Tension nominale:	300V	Épingle:	5 broches
Indice de résistance aux flammes:	UL94-V0	Genre:	Mâle à Femelle
Température de fonctionnement:	-40 ℃ ~ + 105 ℃	Matériel:	PA66
Mettre en évidence:	M19 waterproof power connector 300V , 5 pin panel mount connector , quick lock waterproof circular connector

M19 Watertight Power Connector 300V 5 Pin Panel Mount Quick Lock Connector

Product Overview

5 Pin Circular M19 PA66 300V Male To Female Waterproof Connector designed for reliable power transmission in demanding environments.

Main Features

Push lock quick release system for easy connection
Multiple pin configurations: 2Pin, 3Pin, 4Pin, 5Pin for power applications
Combined power and signal options: 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin
Signal-only variants: 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin
Field assembly versions available for wire-to-wire and wire-to-board applications
Rated for 20A continuous current operation
Cable assembly services supported with custom options
OEM/ODM partnerships welcome

Product Description

Constructed from high-strength PA66 material, this M19 5-pin circular connector supports 300V high-voltage transmission. Featuring a male-to-female design with IP67 waterproof and dustproof rating, it's ideal for diverse power connection scenarios. High-conductivity gold-plated brass pins minimize transmission loss, while the PA66 housing withstands extreme temperatures (-40℃ to +105℃), corrosion, and aging. Equipped with foolproof alignment and secure locking mechanism, it ensures safe and reliable plugging operations. Widely used in industrial control systems, high-voltage lighting, and outdoor testing equipment.

Electrical Parameters

Number of Poles	5Pin
Current Rating	20A maximum
Voltage Rating	300VAC maximum
Durability Voltage	1000VAC @ 60 seconds

Technical Parameters

Contact Resistance	10 mΩ maximum
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C to +105°C
IP Class	IP67 (1m / 30min) when mated
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Operation Parameters

Voltage Rating	600VAC maximum
Current Rating	15A maximum
Minimum Wire Size OD	3.0mm to 6.0mm
Maximum Wire Size OD	8.0mm to 10.0mm
Maximum Cable Cross Section Area	0.5mm² to 2.5mm²

Application Industries

Growth Lights
Communications Equipment
Product Coding Machines
Inventory Product Coding Systems
Inkjet Systems
Solar Systems
Industrial Inkjet Equipment
Electric Power Equipment
Laboratory Forensic & Pathology Equipment
Heavy Machinery
